The B270 series delivers an advanced binocular compound microscope designed for most student or professional applications. With its protective antimicrobial coating, enhanced LED lighting, Siedentopf head adjustments, quadruple turret with four plan objectives, coaxial coarse and fine focus, this microscope is an ideal solution for any laboratory or classroom facility.

Microbe-Resistant Protection

Developed with a protective microbe-resistant coating, the B270 series microscope utilizes a revolutionary paint treatment that works to restrict the growth of microorganisms, including bacteria and mold, which makes it an ideal solution for any laboratory environment.

Viewing Head

The B270 series compound microscope is designed with a Siedentopf binocular head. To customize the microscope to your viewing comfort, the eyepiece spacing can be easily adjusted by simply swiveling the eyepieces. A diopter is available on the left ocular tube to compensate for asymmetry, and the ocular tubes are angled at 30° to comfortably accommodate a seated position without neck strain. Various eyepieces can be used to increase the overall optical magnification.

Optics

The objective turret provides instant access to 4 magnification levels to easily focus in on minute details from 40X to 1000X. This covers magnifications needed for studying hair follicles, cells, and bacteria. These high-quality lenses are achromatically corrected to improve resolution and color accuracy.

Stage

The 2-layer mechanical stage provides smooth and precise movement for examination of specimen slides. The stage's low-position controls are conveniently placed near the coaxial focus knobs for a streamlined workflow. Examining specimen slides is intuitive and precise for users at any skill level.

Transmitted Illumination

The LED sub-stage lighting provides cool, energy-efficient illumination. The light-source is daylight balanced to produce natural colors for imaging. With our specially developed fly-eye lens, the light is evenly distributed at maximum brightness to improve contrast and resolution. Illumination is further enhanced by a centerable Abbe condenser, which can be realigned for any magnification to guarantee proper lighting.

Security

Protect your investment by using the premium microscope lock with key. The B270 microscope incorporates the use of a microscope lock that acts as a theft deterrent, discouraging to casual thieves.

Specifications

Optical System	Finite-conjugate

Mechanical Tube Length	160mm

Head	Binocular, 30° incline, 360° rotatable

Interpupillary Adjustment	Siedentopf, 53-77mm

Ocular Diameter	23mm

Eyepieces	10X

Objective Lenses	DIN standard

Objective Parfocal Distance	45mm

Objective Mounting Thread	RMS 20.32mm

Objective Turret	quadruple

Focusing System	Coaxial coarse and fine focus

Focus Range	25mm

Division of Fine Focus	0.002mm

Stage Design	Double-layer with caliper

Stage Dimensions	118mm x 127mm

X-Y Translation Range	70mm x 21mm

Transmitted Illumination	Variable-intensity 1W LED, fly-eye lens

Condenser	NA1.25 Abbe condenser with iris diaphragm

Sub-stage Condenser-holder	rack and pinion, centerable

Power	100-240VAC 50/60Hz wide-band

Objective Lenses

Magnification	Corrections	NA	Immersion Medium	Cover-glass Thickness
4X	achromatic	0.10	—	0.17mm
10X	achromatic	0.25	—	0.17mm
40X	achromatic	0.65	—	0.17mm
100X	achromatic	1.25	oil	0.17mm

What’s in the Box

One binocular microscope head	One set microscope lock with key
One microscope body	One set of 50 pack blank slides
Four objective lenses: 4X, 10X, 40X, 100X	One set of 100 pack cover slips
One pair 10X eyepieces	One set of 25 plastic pipettes
One dust cover	One blue color filter
One sample immersion oil
